Main features:

• Digital RSSI function
• Automatic frequency correction
• Automatic gain control
• Fast wake-up and frequency hopping
• Highly configurable data packet handler
• SMA Antenna



MCU	ESP32
Flash	4MB
Serial Chip	CH9102
Wireless protocol	Wi-Fi + Bluetooth 4.2
Support	TF card slot
Onboard functions	Reset \ Power switch
Antenna	3D WiFi Antenna [Use by default] LoRa antenna:  Support Lora external antenna, but you need to jump resistance
Power Supply	Support USB Micro / Li-Po Battery Dual Power Supply JST GH 2pin 1.25mm [USB can power the battery]

What's In The Box

433/868/915 Mhz CH9102F Options

(Notice: The shipping list does not include battery and SD card）

• 1 X LoRa32
• 1 X Power Cable(Jst 2pin 1.25mm)
• 1 X Antenna
• 2 X Pin
