UHF RFID Windshield Tag – Technical Specifications

General Description

The UHF RFID Windshield Tag is a passive RFID label designed for vehicle identification and access control systems. It is typically mounted on the inside of a vehicle windshield and provides reliable long-range reading for applications such as parking management, toll collection, and fleet tracking.

---

Main Specifications

Parameter	Specification
Product Type	UHF RFID Windshield Tag
RFID Standard	EPC Class1 Gen2 / ISO 18000-6C
Frequency	860 – 960 MHz
Chip Type	Optional (Alien Higgs / Impinj Monza / NXP UCODE depending on version)
Working Mode	Passive (no battery required)
Reading Distance	Up to 5 – 10 meters (depending on reader and environment)
Memory	EPC: 96–128 bits (typical)
Material	PET / Paper RFID Label
Installation	Adhesive sticker for windshield mounting

---

Physical Specifications

Parameter	Specification
Tag Type	Adhesive RFID label
Color	White
Shape	Rectangular with extended tail antenna
Thickness	~0.2 – 0.4 mm
Mounting	Self-adhesive

Typical dimensions (may vary by manufacturer):

---

Performance Characteristics

• Long-range vehicle identification

• Fast multi-tag reading capability

• Waterproof and weather resistant

• Tamper-resistant design when installed on glass

• Stable performance on vehicle windshields

---

Applications

• Parking access systems

• Electronic toll collection (ETC)

• Vehicle fleet management

• Smart transportation systems

• Secure vehicle identification

• Campus and residential gate control

---

Environmental Specifications

Parameter	Specification
Operating Temperature	-20°C to +70°C
Storage Temperature	-40°C to +85°C
Humidity	5% – 95% RH
